The gate leaves are constructed from a 60 x 40mm RHS perimeter frame with 25mm diameter tubes fitted vertically at 125mm centres. A mid-rail is supplied for strengthening purposes.
Galvanised steel inverted channel section in which pulleys mounted on each leading edge run in and on.
The gates are supported on floor bearings mounted at the side behind each jamb.
The standard arrangement comprises two leaves each side folding at 90 degrees to the opening.
Handles are attached to each leading edge to allow manual operation in the event of power failure.
Galvanised as standard. Polyester powder coating to a range of standard RAL colours is available at extra cost.
Varies dependant on gate construction but typically 40 kgs per m2.
Electrical operation is via two single phase motors mounted on the top of each pair of leaves with a common control panel and operating buttons. Disconnection to manual operation is provided in the event of power failure. Other controls are available at extra cost.
